These are notes for my reading of the segment anything paper. Check out the orignal project page by Meta AI at the link below
Segment Anything by Meta AIHigh Level#
Main idea behind the model is to build a foundational model for Computer Vision similar to the state of the NLP community + allow it to be promptable.
This model can then be used for downstream segmentation problems using prompt engineering and for some cases zero shot finetuning.
They mention 3 main parts of the project as -
What task will enable zero-shot generalization?
Chose promptable segmentation, as it is a suitable pretraining task for a lot of CV problems.
Goal of the task is to return a valid segmentation mask given any segmentation prompt.
What is the corresponding model architecture?
Real-time flexible promptable model
Flexible here means it must be able give a valid segmentation mask for any prompt.
Since the model is supposed to be interactive, it needs real time outputs.
Model -
a powerful image encoder computes an image embedding
a prompt encoder embeds prompts
Image an prompt embedding sources are combined in a lightweight mask decoder that predicts segmentation masks
Types of supported prompts -
Box
Mask
Point
Free form text
What data can power this task and model?
To build the dataset, they use the model for labelling. They call this the “data engine”
To achieve strong generalisations to new data distributions, it was necessary to train SAM on large and diverse set of masks.
No existing dataset satisfied these requirements.
They use ‘model in the loop’ annotation.
3 stages to the “data engine” -
Assisted-manual
- Model assists annotators in annotation.
Semi-auto.
Model can generate annotations for a subset of objects by prompting with likely object locations and masks. (is this because of good performance after stage 1?)
Annotators annotate the rest of the objects.
Fully auto
Model is prompted with a regular grid of foreground points. (what does this mean?)
This results in generation of ~100 high quality masks per image
Final dataset - The final dataset, SA-1B, includes more than 1B masks from 11M licensed and privacy-preserving images. The masks were manually verified to have good annotations.
Focused on AI ethics to look at potential geographical and racial biases the model might have
Experiments
Tested using 23 segmentation datasets to find out that it generated high-quality masks from a single foreground point, these annotations were only slightly below the ground truth.
Got good results on zeroshot downstream tasks such as edge detection, object proposal generation, instance segmentation and preliminary exploration of text-to-mask prediction
These results suggest that SAM can be used out-of-the-box with prompt engineering to solve a variety of tasks involving object and image distributions beyond the model’s training data.
Task#
- The promptable segmentation task is to return a valid segmentation mask given any prompt.
- “Valid” here means that a segmentation mask should be returned even if the prompt is ambiguous. Look at the figure below to understand what ambiguous means here.
This task was chosen since it acts as a natural pre-training algorithm and a general method for zero-shot transfer to downstream tasks via prompting.
One suggested method of using for downstream instance segmentation
- For example, if one has a bounding box detector for cats, cat instance segmentation can be solved by providing the detector’s box output as a prompt to our model.
An important distinction pointed out by them is that the model is not trained in a multitask scenario but can perform different tasks at inference tasks by pairing it with different components.
Model#
Three main components -
image encoder
They use masked autoencoder (MAE) pre-trained ViT adapted to process high res outputs.
What is a masked autoencoder?
a flexible prompt encoder
Prompts are broken down into 2 categories-
Sparse - points, boxes and text
Dense - mask
Points and boxes are encoded using positional embeddings
Text is converted to embeddings using CLIP encoder.
Dense prompts are encoded using convolutional operations.
fast mask decoder
The mask decoder efficiently maps the image embedding, prompt embeddings, and an output token to a mask.
The modified decoder block uses prompt self-attention and cross-attention in two directions (prompt-to-image embedding and vice-versa) to update all embeddings.
After running two blocks, we upsample the image embedding and an MLP maps the output token to a dynamic linear classifier, which then computes the mask foreground probability at each image location
The model was modified to allow for multiple masks being generated for a single prompt. This is to tackle ambiguity in the prompts. They set the limit of masks generated to 3, as they found it to be sufficient for most usecases.
The model is designed to be efficient. The image encoder is the computationally heavy part of the model, afterwards the prompt encoder and mask decoder can run efficiently even in a browser.
This design allows testing the model with different prompts very easily, since the image embeddings don’t need to be computed repeatedly.
Mask prediction - dice + focal loss was used for training.
Data Engine#
The data engine has three stages -
model-assisted manual annotation stage
Normal image annotation assisted by the model in an interactive browser UI environment
No named labels for the objects were collected.
The model was trained on common segmentation datasets before this and then on the slice of the data that had been annotated in stage 1.
4.3M masks were collected from 120k images in this stage.
Model was trained 5-6 times during this phase
semi-automatic stage with a mix of automatically predicted masks and model-assisted annotation
The aim here was to increase the diversity of masks in order to improve the models ability to segment anything.
The model was allowed to make predictions first and then the less common objects were labelled by the annotators.
Model was trained 5-6 times during this phase.
fully automatic stage in which our model generates masks without annotator input
Enough data had been collected by this point to allow for the model to train automatically.
The model was prompted with 32 x 32 grid of points and tasked to predict the masks for these.
The concept of stable mask is introduced, a mask is stable if thresholding the probability map at 0.5 - delta and 0.5 + delta results in similar masks.
delta = 0.3
mask_over = mask > 0.5 + delta
mask_under = mask > 0.5 - delta
similarity(mask_over, mask_under)
After selecting confident masks NMS was applied to filter duplicates.
Fully automatic mask generation was applied to 11M images to generated 1.1B masks.
The SA-1B dataset has been released online, it consists of only generated masks.
A comparison of the generated masks was done with manually annotated masks and showed that the quality of the generated masks is good.
The authors performed a bias and fairness analysis of the dataset as well.
Zero-shot Experiments#
They analysed the performance of the model on different zero-shot experiments.
The tasks are as follows -
Edge detection
Generated segmentation masks and removed duplicates using NMS. These were generated by prompting the model with 16x16 grids of foreground points.
Edge maps are then computed using sobel filtering of un-thresholded mask probability maps and postprocessing.
It produced reasonable edge maps.
Object proposal generation
- To generate object proposals, they ran a slightly modified version of the automatic mask generation pipeline and output the masks as proposals.
Instance segmentation
Segment objects from free-form text
